Cooling curtain for poultry house paper evaporation cooling pad PVC frame alloy frame
Cooling curtain, a vital component for poultry house greenhouse environment control equipment, employs a paper evaporation cooling pad encapsulated within a sturdy frame. This pad, made from high-quality materials, operates on the principle of evaporation, providing effective cooling by utilizing the natural process of water turning into vapor.
Product description
Evaporative cooling curtain is mainly used for ventilation and cooling on poultry farms, livestock farms, greenhouses, factories, etc.
● Our cooling curtain is produced with new materials and space crossing linking technology, high water absorbability ,high water-resistance, anti-mildew and long service life
● The cooling contains surface active agent for natural water absorbability ,fast pervasion speed, lasting effectiveness.
● Strict production as per standard, width of 600mm cooling pad involves 85 sheets
● Raw material adopts imported kraft paper, we have 95g/sqm and 105g/sqm for your choice. Tension resistance at 70N, Absorbability height as 45mm/10min, moisture at 5-8%, humidity at 18N
● Our cooling curtain doesn’t contain Phenol or any other chemical substances which easily makes skin allergy. Non-toxic and harmless to human body, safety, energy saving, environment protection and economic applicable.
● ● According to different requirements ,we can offer color-coated cooling curtain for easy cleaning and beautiful appearance.
● ● Regular colors: black coated/ green coated/ yellow coated/ red coated/blue coated/ orange coated and so on.
Product Parameter
|
Model |
Height(mm) |
Width(mm) |
Thickness(mm) |
Flute |
Angle |
|
7090 |
1500/1800/2000/Customized |
300/600/Customized |
100/150/200/Customized |
7mm |
45°/45° |
|
7060 |
1500/1800/2000/Customized |
300/600/Customized |
100/150/200/Customized |
7mm |
45°/45° |
|
5090 |
Customized |
Customized |
Customized |
5mm |
45°/45° |
From design planning, installation and commissioning to post-training, we provide a full range of one-stop services, freeing customers from the tedious breeding preparations and focusing on the breeding itself.
